One element
 | Electrical specifications
| Model |
D4 FMW-3 |
D4 FMW-5
|
| Operating frequency band, MHz |
88-108 |
88-108
|
| VSWR, not more than |
1.2 |
1.2
|
| Gain OMNI, dBi |
9.7 |
9.7
|
| Sector in vertical plane , -3dB |
180 |
180
|
| Impedance, Ohm |
50 |
50
|
| Max. power input, W |
3000 |
5000
|
Mechanical specifications
| Model |
D4 FMW-3 |
D4 FMW-5
|
| Weight, kg |
40 |
43
|
| Size, mm |
9000x1450x80 |
9000x1450x80
|
| Construction material |
Aluminium alloy |
Aluminium alloy
|
| Temperature range, 0C |
from -50 to +50 |
from -50 to +50
|
| Connector |
7/16 DIN |
EIA 7/8
|
| |
|
D4 FMW E-plane pattern.
D4 FMW H-plane pattern
VSWR, D1 FMW
|
| |
|
 |
