| | Electrical specifications
| Impedance in, Ohm |
50
|
| Impedance out, Ohm |
50
|
| VSWR @BP=300 kHz |
1,2
|
| Temperature range, °C |
+20° ± 10°
|
| Relative humidity % |
80
|
| Insertion loss @BP=300 kHz, dB |
0,10-0.47
|
| Input power 1st channel, W |
2000
|
| Input power 2nd channel, W |
1000
|
| Input power 3rd channel, W |
2000
|
| Isolation TX1-TX2 not less, dB |
34
|
| Isolation TX1-TX3 not less, dB |
39
|
| Isolation TX2-TX3 not less, dB |
80
|
|
|
Mechanical specifications
| Connector in |
7/16 DIN
|
| Connector out |
EIA 1 5/8
|
| Demensions, mm |
1000x1350x1550
|
| Weight, kg |
120
|
| |
| |
|
 |
